Ethereum Testnet Validator

This repository is a one-click deployment solution for running an Ethereum node (testnet) on a VM (GCP).
Current Implementation: Ansible-based deployment with Nethermind (execution) + Nimbus (consensus)

Table of Contents

• Current Architecture
• Prerequisites
• Quick Start
  • Command 1: Provision Infrastructure
  • Command 2: Start Validator
  • Command 3: Check Health
• Monitoring and Management
  • Service Logs
  • Sync Status Queries
  • Metrics Endpoints
• Configuration
  • Inventory Configuration
  • Testnet Selection
• Project Structure
• Documentation
• Security & Key Management
  • KMS-Encrypted Validator Keys
  • General Security
• License
• Acknowledgments
• Support

Current Architecture

Deployment: GCP Compute Engine VM with Ansible automation

Prerequisites

Target System Requirements

• OS: Ubuntu 22.04/24.04 LTS
• CPU: 8+ cores
• RAM: 32GB+ (minimum for Testnet)
• Disk: 1TB+ SSD (persistent storage)
• Network: Stable connection, ports 22, 30303, 9000 open

Control Machine Requirements

• Ansible: 2.14+ installed locally
• SSH: Key-based authentication to target VM
• Git: For cloning repository

Quick Start

These are the ONLY 3 commands needed from a clean environment:

Command 1: Provision Infrastructure

sudo ./scripts/provision.sh

What it does:

• Validates system requirements (CPU, RAM, disk, ports)
• Runs Ansible playbook to deploy full validator stack
• Sets up disk partitioning and mounting
• Creates system users (execution, consensus, validator)
• Configures SSH hardening and firewall
• Installs Nethermind (execution client)
• Installs Nimbus (consensus + validator clients)
• Configures JWT authentication between clients
• Generate validator keys and store it on KMS
• Creates systemd services for all components

Duration: ~10-30 minutes Output: Infrastructure ready, services configured

---

Command 2: Start Validator

sudo ./scripts/start-validator.sh
#NOTE: The *provision.sh* already start everything automatically.

What it does:

• Deploys Ethereum validator stack via Ansible
• Starts execution.service (Nethermind)
• Starts consensus.service (Nimbus beacon)
• Waits for execution layer to be responsive
• Initializes consensus client with checkpoint sync
• Verifies all services are running

Duration: ~2-3 minutes Output: All services running, beginning sync to Hoodi testnet

---

Command 3: Check Health

./scripts/check-health.sh

What it does:

• Queries execution client RPC (port 8545)
• Queries consensus client REST API (port 5052)
• Displays sync status (syncing vs synced)
• Shows peer connections
• Shows serivices status
• Reports validator status (if keys imported)
• Displays resource usage (disk, memory)
• Returns exit code 0 (healthy) or 1 (unhealthy)

Example Output:

============================================================
__________ __  .__
\_   _____//  |_|  |__   ___________   ____  __ __  _____
 |    __)_\   __\  |  \_/__ \_  __ \_/ __ \|  |  \/     \
 |        \|  | |   Y  \  ___/|  | \/  ___/|  |  /  Y Y  /
/_______  /|__| |___|  /\___  >__|    \___  >____/|__|_|  /
        \/           \/     \/            \/            \/
____   ____      .__  .__    .___       __
\   \ /   /____  |  | |__| __| _/____ _/  |_  ___________
 \   Y   /\__  \ |  | |  |/ __ |\__  \   __\/  _ \_  __ \
  \     /  / __ \|  |_|  / /_/ | / __ \|  | (  <_> )  | \/
   \___/  (____  /____/__\____ |(____  /__|  \____/|__|
               \/             \/     \/
============================================================

[INFO] Script: Validator Health Check
[INFO] Wed Oct 22 13:52:17 CEST 2025
[INFO] Server: 34.44.182.36

━━━ System Services ━━━

[✓] Execution Layer (Nethermind) is running
[✓] Consensus Layer (Nimbus Beacon) is running
[✓] Validator Client (Nimbus Validator) is running

━━━ Execution Layer Status ━━━

[✓] Execution client is fully synced
[INFO]   Current block: 1466445
[✓] Connected to 50 execution peers

━━━ Consensus Layer Status ━━━

[⚠] Consensus client is syncing...
[✓] Connected to 47 consensus peers

━━━ Validator Status ━━━
[✓] Found        1 validator key(s)

[⚠] Chain is still syncing
[INFO]   Validator status will be available once chain is synced
[INFO]   Current slot: 1576713
[INFO]   Current epoch: 49272
[INFO]   Validator 1: 0x8a5fb247...b97784
━━━ Resource Usage ━━━

[INFO] Disk usage: 59G/984G (7%)
[INFO] Memory usage: 5.3Gi/31Gi

━━━ Health Summary ━━━

[⚠] Status: SYNCING

  ⏳ Clients are syncing to network
  ℹ️  This is normal for new deployments

[INFO] Estimated sync time:
[INFO]   • Execution client: 2-4 hours (depending on network)
[INFO]   • Consensus client: 15-30 minutes (with checkpoint sync)
[INFO] Re-run this check periodically to monitor progress.

Duration: ~5-10 seconds Output: Human-readable health status

Monitoring and Management

Service Logs

# View execution client logs
ssh <vm-ip> 'sudo journalctl -fu execution'

# View consensus client logs
ssh <vm-ip> 'sudo journalctl -fu consensus'

# View validator client logs
ssh <vm-ip> 'sudo journalctl -fu validator'

Sync Status Queries

# Execution sync status (via RPC)
curl -X POST -H "Content-Type: application/json" \
  --data '{"jsonrpc":"2.0","method":"eth_syncing","params":[],"id":1}' \
  http://<vm-ip>:8545

# Consensus sync status (via REST API)
curl http://<vm-ip>:5052/eth/v1/node/syncing | jq

# Peer counts
curl http://<vm-ip>:5052/eth/v1/node/peer_count | jq

Metrics Endpoints

• Nethermind: http://<vm-ip>:9090/metrics (Prometheus format)
• Nimbus Beacon: http://<vm-ip>:8008/metrics (Prometheus format)
• Nimbus Validator: http://<vm-ip>:8009/metrics (Prometheus format)

Configuration

Inventory Configuration

Edit ansible/inventory/hosts.yml to customize:

all:
  children:
    validator:
      hosts:
        eth_validator_vm:
          ansible_host: <YOUR_VM_IP> # Change this
          ansible_user: <YOUR_USERNAME> # Change this

  vars:
    # Testnet selection
    testnet_network: "hoodi" # or "holesky"

    # Fee recipient (CHANGE THIS!)
    fee_recipient_address: "0xYourEthereumAddress"

    # Client versions (auto-download latest)
    nethermind_version: "latest"
    nimbus_version: "latest"

    # System requirements
    min_cpu_cores: 4
    min_memory_gb: 30
    min_disk_gb: 500

Testnet Selection

• Hoodi (default): Recommended, stable, active validator set
• Holesky: Alternative testnet, smaller validator set

Change in ansible/vars/common.yml or inventory

Project Structure

├── scripts/
│   ├── provision.sh                # Command 1: Infrastructure setup
│   ├── start-validator.sh          # Command 2: Start validator
│   └── check-health.sh             # Command 3: Health check
│
├── ansible/                        # Ansible automation
│   ├── playbooks/
│   │   ├── deploy_validator.yml        # Main deployment playbook
│   │   ├── preflight.yml                # System validation
│   │   └── validate.yml                # Post-deployment checks
│   ├── secure/                         # Save mnemonic and validator files
│   ├── roles/
│   │   ├── disk_setup/                 # Disk partitioning
│   │   ├── system_users/               # User creation
│   │   ├── security_hardening/         # SSH + firewall
│   │   ├── jwt_secret/                 # JWT generation
│   │   ├── nethermind/                 # Execution client
│   │   ├── nimbus/                     # Consensus + validator
│   │   └── validator_orchestration/    # Service startup
│   ├── inventory/
│   │   └── hosts.yml                   # Target hosts config
│   └── vars/
│       └── common.yml                  # Common node variables
│       └── holesky.yml                 # Testnet holesky variables
│       └── hoodi.yml                   # Testnet hoodi variables
│
├── terraform/                 # GCP infrastructure (optional)
│   ├── main.tf                # VM provisioning
│   ├── modules/               # Reusable modules
│   └── variables.tf           # Configuration
│
└── docs/                      # Documentation
    ├── CHALLENGE.MD           # Original challenge
    ├── TODO.md                # Implementation checklist
    └── ARCHITECTURE.md        # Design details

Documentation

• Architecture - System architecture and design decisions
• KMS Key Management - KMS keys and management
• Ansible Guide - Detailed Ansible automation guide
• Hoodi Validator Registration - Detailed Hoodi validator registration
• Runbook - Runbook

Security & Key Management

KMS-Encrypted Validator Keys (Bonus Feature)

Production-grade key encryption using Google Cloud KMS ensures validator private keys are never stored in plaintext:

Key Lifecycle:
1. Generate keys locally (EthStaker deposit-cli)
2. Encrypt with Cloud KMS → ./ansible/scripts/encrypt-and-upload-keys.sh
3. Store encrypted in GCS bucket
4. On validator start: decrypt to tmpfs (memory-only)
5. On validator stop: securely wipe from memory

Security Features:

• AES-256 Encryption - Industry-standard Cloud KMS encryption
• Automatic Key Rotation - 30-day rotation policy
• Memory-Only Storage - Decrypted keys never touch disk (tmpfs)
• Secure Deletion - Keys wiped with shred on service stop
• Audit Logging - All KMS operations logged to Cloud Logging
• IAM Access Control - Minimal permissions (decrypt only)

Quick Start:

# 1. Encrypt local validator keystores
./scripts/encrypt-and-upload-keys.sh

# 2. Deploy validator (keys auto-decrypted on start)
sudo ./scripts/start-validator.sh

# 3. Verify key decryption
ssh <vm-ip> 'sudo journalctl -t validator-keys -f'

Documentation:

• KMS Key Management Guide

License

MIT

Acknowledgments

• Ethereum Foundation
• Hoodi Ethereum Explorer
• Validator Cheklist
• Becoming a Hoodi Validator
• Hoodi Faucet
• Validator's List

Support

For support, please open an issue on GitHub Issues.
