Acrool React Grid

CSS IN JS following Bootstrap RWD design, composed of React + Styled Component

Version	Styled-component	React
6.x	6.x	^18.3
5.x	5.x	18.0 ~ 18.3

Documentation

• Getting Started
• Faq
• Config
• Utilities
• Breakpoints
• Container
• Grid System
• CSS Grid
• Storybook

Features

• Use React + Styled-component and styled-component themeProvider
• Easier to use
• Refer to the design of Bootstrap 5 and change it to CSS IN JS method
• Provides tool CSS for Bootstrap 5 layout
• Provide RWD Media query method
• Support NextJS 14 (v5.0.3+)
• Container max width --container-max-width-? Change from the middle level

Installation

yarn add styled-components @acrool/react-grid

in your packages. (Make the version of styled-component you use match the version of styled-component used in acrool-react-gird)

{
    "resolutions": {
        "styled-components": "6.1.17"
    }
}

in your App.js add
see the example/src/App.js

import {GridThemeProvider, IGridSetting} from '@acrool/react-grid';
import '@acrool/react-grid/dist/index.css';


const gridTheme: IGridSetting = {
    spacer: '1rem',
    gridColumns: 12,
    gridBreakpoints: {
        xs: 0,
        sm: 576,
        md: 768,
        lg: 992,
        xl: 1200,
        xxl: 1540,
    },
    containerMaxWidths: {
        sm: 540,
        md: 720,
        lg: 960,
        xl: 1140,
        xxl: 1141,
    },
}


<GridThemeProvider gridTheme={gridTheme}>
    <App/>
</GridThemeProvider>

Override css setting

create folder and file: src/library/acrool-react-grid/grid.scss

@use "@acrool/react-grid/dist/styles.scss" with (

    // 定义断点
    $breakpoints: (
        sm: 576px,
        md: 768px,
        lg: 992px,
        xl: 1200px,
        xxl: 1440px
    ),

    // 网格系统变量
    $grid-gutters: (
        1: 2px,
        2: 4px,
        3: 6px,
        4: 8px,
        5: 10px,
        6: 12px,
        7: 14px,
        8: 16px,
        9: 18px,
        10: 20px,
        11: 22px,
        12: 24px,
        13: 26px,
        14: 28px,
        15: 30px,
        16: 32px,
        17: 34px,
        18: 36px,
        19: 38px,
        20: 40px,
        21: 42px,
        22: 44px,
        23: 46px,
        24: 48px,
        25: 50px,
        26: 52px,
        27: 54px,
        28: 56px,
        29: 58px,
        30: 60px,
        31: 62px,
        32: 64px,
        33: 66px,
        34: 68px,
        35: 70px,
        36: 72px,
        37: 74px,
        38: 76px,
        39: 78px,
        40: 80px,
        41: 82px,
        42: 84px,
        43: 86px,
        44: 88px,
        45: 90px,
        46: 92px,
        47: 94px,
        48: 96px,
        49: 98px,
        50: 100px,
        51: 102px,
        52: 104px,
        53: 106px,
        54: 108px,
        55: 110px,
        56: 112px,
        57: 114px,
        58: 116px,
        59: 118px,
        60: 120px,
        61: 122px,
        62: 124px,
        63: 126px,
        64: 128px,
        65: 130px,
        66: 132px,
        67: 134px,
        68: 136px,
        69: 138px,
        70: 140px,
        71: 142px,
        72: 144px,
        73: 146px,
        74: 148px,
        75: 150px,
        76: 152px,
        77: 154px,
        78: 156px,
        79: 158px,
        80: 160px,
        81: 162px,
        82: 164px,
        83: 166px,
        84: 168px,
        85: 170px,
        86: 172px,
        87: 174px,
        88: 176px,
        89: 178px,
        90: 180px,
        91: 182px,
        92: 184px,
        93: 186px,
        94: 188px,
        95: 190px,
        96: 192px,
        97: 194px,
        98: 196px,
        99: 198px,
        100: 200px
    )
);

Examples

use in your page/component:

import {Container, Row, Col, Grid, Flex, media} from '@acrool/react-grid';

const MyPage = () => {
    return (
        <Container>
            <MyTitle>acrool-react-grid</MyTitle>
            <Desc isVisible={false}>myDesc</Desc>

            <Row>
                <Col col>col2 (50%) </Col>
                <Col col>col2 (50%) </Col>
            </Row>
            <Grid columns={2}>
                <div>Grid Col2</div>

                <Flex className="flex-column gap-2">
                    <div>Grid Col3</div>
                    <div>Grid Col3</div>
                </Flex>


            </Grid>
            <Grid columns="repeat(1, 3fr)">
                <GridCol>Grid Col3</GridCol>
                <GridCol colSpan={2}>Grid Col3</GridCol>
            </Grid>
        </Container>
    );
}

// use rwd
const MyTitle = styled.div`
    font-size: 12px;
    ${media.md`
        font-size: 14px;
    `}
`

// use rwd props
const Desc = styled.div<{
    isVisible: boolean
}>`
    ${props => media.md`
        display: ${props.isVisible ? 'block': 'flex'}
    `}

    // or
    ${props => css`
        font-size: 12px;
        ${media.md`
            display: ${props.isVisible ? 'block': 'flex'}
        `}
    `}
`

MediaConsumer

<MediaConsumer sizes={['xxl']}>
    {(mediaSize)=> {

        if(mediaSize === 'xxl'){
            return <Marquee
                autoFill
                play={hoverId === null}
                className="py-8"
            >
                {renderCards(true)}
            </Marquee>;
        }


        return <Container fluid>
            <Flex column className="gap-8">
                {renderCards(false)}
            </Flex>
        </Container>;
    }}
</MediaConsumer>

There is also a codesandbox template that you can fork and play with it:

Acrool React Grid Template

Use Nextjs example

Acrool React Grid Nextjs Template

There is also a storybook that you can play with it:

License

MIT © Acrool & Imagine
