[core] Support publishing events from aggregator to gcs #55781
Conversation
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
![gemini-code-assist[bot]](https://avatars.githubusercontent.com/in/956858?s=60&v=4){kind=small}
There was a problem hiding this comment.
Code Review
This pull request adds support for publishing Ray events from the aggregator to GCS. The changes include a new GCSPublisher, a TaskMetadataBuffer to handle task-related metadata, and associated configurations, metrics, and tests. The implementation is solid, but I've found a few areas for improvement. There's a high-severity bug in TaskMetadataBuffer where a method has inconsistent return types, which could lead to runtime errors. I've also pointed out a couple of medium-severity issues in GCSPublisher related to type hint correctness and overly broad exception handling. Addressing these points will improve the robustness and maintainability of the new functionality.
python/ray/dashboard/modules/aggregator/task_metadata_buffer.py
Outdated
Show resolved
Hide resolved
python/ray/dashboard/modules/aggregator/ray_events_publisher.py
Outdated
Show resolved
Hide resolved
python/ray/dashboard/modules/aggregator/ray_events_publisher.py
Outdated
Show resolved
Hide resolved
Signed-off-by: sampan <[email protected]>
|
will review after other is merged |
ray-gardener
bot
added
core
Signed-off-by: sampan <[email protected]>
Signed-off-by: Sampan S Nayak <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: Sampan S Nayak <[email protected]>
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
| if PUBLISH_EVENTS_TO_GCS: | ||
| logger.info("Publishing events to GCS is enabled") | ||
| self._event_processing_enabled = True | ||
| self._async_gcs_channel = create_gcs_channel(self.gcs_address, aio=True) |
There was a problem hiding this comment.
Don't use create_gcs_channel which use python grpcio. Use GcsClient from cython instead.
python/ray/dashboard/modules/aggregator/publisher/async_publisher_client.py
Outdated
Show resolved
Hide resolved
Signed-off-by: sampan <[email protected]>
![cursor[bot]](https://avatars.githubusercontent.com/in/1210556?s=60&v=4){kind=small}
python/ray/dashboard/modules/aggregator/publisher/async_publisher_client.py
Show resolved
Hide resolved
Signed-off-by: sampan <[email protected]>
| ): | ||
| self._buffer_maxlen = max( | ||
| max_buffer_size - 1, 1 | ||
| ) # -1 to account for the current batch |
There was a problem hiding this comment.
Bug: Buffer Capacity Miscalculation
The _buffer_maxlen calculation max(max_buffer_size - 1, 1) causes the buffer to exceed its intended total capacity. When max_buffer_size is 1, the buffer can hold two entries (one in the deque, one in the current batch), instead of the configured one.
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
| DEFAULT_HTTP_EXPOSABLE_EVENT_TYPES = ( | ||
| "TASK_DEFINITION_EVENT,TASK_EXECUTION_EVENT," | ||
| "ACTOR_TASK_DEFINITION_EVENT,ACTOR_TASK_EXECUTION_EVENT," | ||
| "ACTOR_TASK_EXECUTION_EVENT," |
There was a problem hiding this comment.
nit: changes that are unrelated to this PR? It's fine for now but let's try to put unrelated changes in different PRs to minimize the PR's size. That'll help speed up review and code merging.
There was a problem hiding this comment.
we no longer have a separate event for ACTOR_TASK_DEFINITION_EVENT, so just removing it. should not have any impact
| for task_event in reply.events_by_task: | ||
| if task_event.task_info.name.lower() == unique_task_name.lower(): | ||
| return task_event | ||
| task = list_tasks(filters=[("name", "=", unique_task_name)]) |
| # Max number of threads for the thread pool executor handling CPU intensive tasks | ||
| THREAD_POOL_EXECUTOR_MAX_WORKERS = ray_constants.env_integer( | ||
| f"{env_var_prefix}_THREAD_POOL_EXECUTOR_MAX_WORKERS", 1 | ||
| f"{env_var_prefix}_THREAD_POOL_EXECUTOR_MAX_WORKERS", 2 |
There was a problem hiding this comment.
why are we changing this? will it potentially cause regressions in some release tests ...; ideally let's put it in a different PR if it's not critical for the correctness of this PR
There was a problem hiding this comment.
let me revert this, I did this to handle the scenario where both http and gcs publishers are enabled. in this case we would need two threads for maximum concurrency as the http publisher may use 1 thread to ser-de JSON while gcs publisher also uses 1 thread to ser-de PROTO. but given the fact that we are unlikely to use both publishers in majority of the cases let me set restrict num threads to 1 by default
python/ray/includes/gcs_client.pxi
Outdated
| ############################################################# | ||
| # GcsRpcClient methods | ||
| ############################################################# | ||
| async def async_add_events(self, serialized_request: bytes, timeout_s=None, executor=None) -> int: |
There was a problem hiding this comment.
similarly, this is fine for this PR but should be in another self-contained PR (this PR now is quite large for me to go through every thing in my brain context window ;))
There was a problem hiding this comment.
added this to the current pr because i recently found out that we dont want to use python grpc library instead use cython bindings. I agree, I should have created a pr to add these bindings first and then raise this (current) pr ontop of it. Will keep this in mind next time
| CAddEventsRequest c_req | ||
| int64_t timeout_ms | ||
| fut = incremented_fut() | ||
| timeout_ms = round(1000 * timeout_s) if timeout_s else -1 |
There was a problem hiding this comment.
does a -1 timeout mean it will hang forever? maybe use 30s as a default?
There was a problem hiding this comment.
yeah -1 is the same as having no timeout. I think we can keep this as -1 as this is the default behaviour (I see similar pattern being used by other python libraries, eg http request lib does not have a timeout by default and needs one to be configured explicitly). consumers of this api can override it with a more reasonable value.
| if m.name == descriptor and m.labels[CONSUMER_TAG_KEY] == consumer_name | ||
| ] | ||
| if not samples: | ||
| print("missing: ", descriptor) |
There was a problem hiding this comment.
thanks for flagging this!
Signed-off-by: sampan <[email protected]>
| move(c_req), | ||
| StatusPyCallback(convert_status, assign_and_decrement_fut, fut), | ||
| timeout_ms) | ||
| return await asyncio.wrap_future(fut) |
There was a problem hiding this comment.
Bug: Async Method Threading and Error Handling Issues
The async_add_events method has a critical threading bug: when an executor is used, the stack-allocated c_req C++ object is accessed from a different thread. This cross-thread access to stack memory can lead to memory corruption or crashes. Separately, the method's error handling is inconsistent, raising a ValueError for parse errors while its signature implies an int return.
|
Prior to merging, shall we benchmark this against the baseline of directly sending events from core worker? |
python/ray/includes/gcs_client.pxi
Outdated
| ############################################################# | ||
| # GcsRpcClient methods |
There was a problem hiding this comment.
| ############################################################# | |
| # GcsRpcClient methods | |
| ############################################################# | |
| # GcsRpcClient methods |
src/ray/gcs_rpc_client/rpc_client.h
Outdated
| /// | ||
| /// TODO: Extend this macro to support other callback types defined in | ||
| /// gcs_callback_types.h | ||
| #define VOID_GCS_RPC_CLIENT_METHOD_WITH_STATUS_CALLBACK(SERVICE_NAMESPACE, \ |
There was a problem hiding this comment.
Why do we need to define a new macro here?
There was a problem hiding this comment.
this was added to support gcs::StatusCallback which is required to add the cython bindings for this API. just saw #55781 (comment) . will remove this macro and use the accessor class instead of the rpc client in the cython binding
python/ray/includes/gcs_client.pxi
Outdated
| return await asyncio.wrap_future(fut) | ||
|
|
||
| with nogil: | ||
| self.inner.get().GetGcsRpcClient().AddEvents( |
There was a problem hiding this comment.
we should add a AsyncAddEvents to the TaskInfoAccessor and use it here.
yes I am working on this by running some release tests, seeing some segmentation faults which I am trying to debug |
| move(c_req), | ||
| StatusPyCallback(convert_status, assign_and_decrement_fut, fut), | ||
| timeout_ms) | ||
| return await asyncio.wrap_future(fut) |
There was a problem hiding this comment.
Bug: Error Handling Inconsistency in async_add_events
The async_add_events method handles protobuf parsing errors by raising a ValueError, but gRPC errors return an integer status code. This inconsistency makes error handling unpredictable for callers and conflicts with the -> int return type annotation.
Signed-off-by: sampan <[email protected]>
Signed-off-by: sampan <[email protected]>
| is_publish_successful=False, | ||
| num_events_published=0, | ||
| num_events_filtered_out=0, | ||
| ) |
There was a problem hiding this comment.
Bug: GCS RPC vs HTTP Status Code Comparison Error
The AsyncGCSTaskEventsPublisherClient.publish method incorrectly compares the GCS RPC status code with an HTTP status code, which can misinterpret GCS publishing outcomes. Additionally, on any publishing failure, the returned PublishStats incorrectly sets num_events_filtered_out to 0, losing accurate filtering metrics.
Signed-off-by: sampan <[email protected]>
| "env_vars": { | ||
| # Enable both publishers | ||
| "RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISH_EVENTS_TO_GCS": "True", | ||
| "RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISH_EVENTS_TO_EXTERNAL_HTTP_SVC": "True", |
There was a problem hiding this comment.
Bug: Incorrect Environment Variable Causes Test Failures
The tests use an incorrect environment variable name (RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISH_EVENTS_TO_EXTERNAL_HTTP_SVC instead of RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISH_EVENTS_TO_EXTERNAL_HTTP_SERVICE) to control HTTP event publishing. This prevents the HTTP publisher from being enabled or disabled as intended, leading to inaccurate test results.
Additional Locations (1)
Signed-off-by: sampan <[email protected]>
Signed-off-by: Sampan S Nayak <[email protected]>
| { | ||
| "env_vars": { | ||
| # Disable HTTP publisher to test GCS filtering in isolation | ||
| "RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISH_EVENTS_TO_EXTERNAL_HTTP_SVC": "False", |
There was a problem hiding this comment.
Bug: Ray Dashboard HTTP Publisher Typo
The environment variable RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISH_EVENTS_TO_EXTERNAL_HTTP_SVC has a typo, using _SVC instead of _SERVICE. This prevents the HTTP publisher from being disabled as intended, which could affect tests relying on its isolation.
| ): | ||
| self._buffer_maxlen = max( | ||
| max_buffer_size - 1, 1 | ||
| ) # -1 to account for the current batch |
There was a problem hiding this comment.
Bug: Buffer Capacity Miscalculation
The _buffer_maxlen calculation max(max_buffer_size - 1, 1) incorrectly determines the buffer's capacity. It misaccounts for _current_metadata_batch, leading to an actual total capacity that doesn't align with the max_buffer_size expectation, especially for small values.
5 participants
Why are these changes needed?
This is the second out of two pr's for supporting sending events from aggregator to GCS. this pr builds on top of #55780 to now support publishing ray events to GCS from aggregator.
Related issue number
NA
Checks
git commit -s) in this PR.scripts/format.shto lint the changes in this PR.method in Tune, I've added it in
doc/source/tune/api/under thecorresponding
.rstfile.Note
Adds GCS publishing alongside HTTP for aggregator events, introduces task metadata buffering, and centralizes event filtering/config with updated tests and metrics.
PUBLISH_EVENTS_TO_GCS) alongside HTTP; wireRayEventPublisherforray_gcsandhttp_serviceand run both.TaskMetadataBufferto accumulatetask_events_metadata(dropped task attempts) and include in GCS publishes.AsyncGCSPublisherClientto sendRayEventsDatato GCS with filtering (GCS_EXPOSABLE_EVENT_TYPES).AsyncHttpPublisherClientto self-manage exposable HTTP event types (HTTP_EXPOSABLE_EVENT_TYPES) and remove external filter fn.PublishBatch(now carriestask_events_metadata) and shared exposable-event logic.RAY_DASHBOARD_AGGREGATOR_AGENT_PUBLISHER_HTTP_ENDPOINT_EXPOSABLE_EVENT_TYPES.http_serviceandray_gcs; tests assert consumer-scoped counters.TaskMetadataBuffer.Written by Cursor Bugbot for commit 47b524c. This will update automatically on new commits. Configure here.
