Lyrics

storybrew can help with making a lyrics storyboard by loading subtitle files and automatically generating text sprites. You can find an example of this in scripts/Lyrics.cs.

Loading subtitles

Subtitles can be loaded in your script with the following method:

var subtitles = LoadSubtitles(path);

Where path points to a .sbv, .srt, .ass or .ssa file in your project's folder (not mapset!). This is a standard subtitle file that can be made with a tool like aegisub. These subtitles contain multiple lines that can be accessed this way:

foreach (var line in subtitles.Lines)

Each line has Text, StartTime and EndTime properties.

Generating text sprites

First, you need to declare a font. spritesPath is the place where generated sprites will be saved, for example you can use "sb/font":

var font = LoadFont(spritesPath, new FontDescription() {
    FontPath = "Verdana",
    FontSize = 26,
});

Then you can use it to build text sprites:

var texture = font.GetTexture("Some text");
var sprite = layer.CreateSprite(texture.Path, OsbOrigin.Centre, new Vector2(320, 400));

And by using the previously loaded subtitles, you can display your lyrics :

foreach (var line in subtitles.Lines)
{
    var texture = font.GetTexture(line.Text);
    var sprite = layer.CreateSprite(texture.Path, OsbOrigin.Centre, new Vector2(320, 400));
    sprite.Fade(line.StartTime - 200, line.StartTime, 0, 1);
    sprite.Fade(line.EndTime - 200, line.EndTime, 1, 0);
}

Font specifications

When you declare a new font, you can specify a FontDescription to help format your text sprite. Parameters with a default value are optional.

• FontPath The path to the font file, relative to your project's folder. You can also use the font name instead for fonts installed on the system, but the correct font name can be hard to guess. Required.
• FontSize The font point size. Default value 76.
• Color The font's color, which accepts a Color4 object. Default value is black.
• Padding Blank pixel space surrounding the rendered text sprite, as Vector2. Helpful for aligning a text sprite against a boxed background. Default value is Zero.
